API Line Pipe is steel pipe used for the transmission of Oil, Gas and Petroleum Distillates. Line Pipes are manufactured as per specifications established by American Petroleum Institute (API).
Types Of API Pipes:
API 5L Pipe
API 5L pipes are carbon steel pipes used for oil and gas transmissions. They include pipes manufactured in seamless and welded (ERW, SAW).
View More Details| Grades | API 5L Grade B, X42, X52, X56, X60, X65, X70, X80. |
| Product Specification Level | PSL1, PSL2, onshore and offshore sour services |
| Outer Diameter Range | 1/2” to 2”, 3”, 4”, 6”, 8”, 10”, 12”, 16 inches, 18 inches, 20 inches, 24 inches up to 40 inches. |
| Thickness Schedule | SCH 10. SCH 20, SCH 40, SCH STD, SCH 80, SCH XS, to SCH 160 |
| Manufacturing Types | Seamless (Hot Rolled and Cold Rolled), Welded ERW (Electric resistance welded), SAW (Submerged Arc |
| Ends Type | Beveled ends, Plain ends |
API 5L ERW Pipe
API 5L ERW Pipe is produced under the American Petroleum Institute specifications. The pipes are used in transporting petroleum products and other along a long line of pipes.
View More Details| Grade | GR A, GR B, X42, X46, X52, X56, X60, X65, X70, S275, S355 |
| Sizes | Nominal Size 1/2 inxh to 48 inch O.D. Pipe Wall Thickness - Schedule 10 through 160, STD, XS, XXS. |
| Product Specification Level (PSL) | API 5L ERW PSL 2 , API 5L ERW PSL 1 |
| Thickness | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XS, SCH XXS, All API 5L ERW Pipe Wall Thickness available in stock |
| End | Plain, Bevel, Screwed, Threaded |
| Type | Seamless, Welded, ERW, Fabricated, CDW |
| Length | Single Random, Double Random & Required Length, Custom Size - 12 Meter lengths |
API 5L Grade B Pipe
API 5L Grade B Pipe Wall Thickness - Schedule 10 through 160, STD, XS, XXS. 3LPE, 3LPP, Bare, Oiled, Mill Varnish, Galv, FBE Dual, Coal Tar, Concrete Coating and Tape Wrap Grade B Pipe. Grade B Pipes are Suitable for Conveying gas, water, oil, and other liquefied media. Steel pipes for pipelines for combustible fluids.
View More Details| Product Specification | API 5L, PSL-1, PSL-2 |
| Size | 1/2" to 24", *size above 24” NPS can be arranged on request |
| Schedule | SCH10, SCH 40, SCH 80, SCH 160 To SCH XXS as per thickness mention in API 5L. |
| Type | Seamless, Welded, ERW, L-SAW construction |
| Grade | Grade B And L245 |
